Description
Iguasçu XT is our most compact floorstanding speaker. It integrates the full Waterfall “DNA”: pure and balanced sound reproduction on all types of music. Designed and manufactured with the most advanced industrial processes, its final assembly is done by hand with the same rigorous and precise methods in our factory following true « Made in France » tradition.
ATOHM ABSOLUTE SERIES
CHOICE COMPONENTS
Iguasçu XT is a pure 2 way/2 drivers system. Its ATOHM Absolute series drivers associated to our JETSTREAM technology will take you into the heart of your favourite music.
MATERIAL SELECTION
D.N.A
Glass and Aluminium, our « trademark » materials are obviously the main feature of our smaller model. We apply, to our Iguasçu XT, the same Waterfall « know how » and expertise in execution.
Its precision and beauty are revealed as well, it will bring you similar visual and sonic emotions just like with our other bigger models in the range.
INTEGRATION
VISUAL AND ACOUSTIC FUSION
Whereas many people are trying to hide their ungraceful speakers, you will enjoy integrating our glass pieces into your living spaces. Just like a special piece of jewellery, your room becomes the jewel case. This becomes a mutual showcase.
KEY POINTS
Safety glass, for residential use (indoor)
Unique and timeless design, blends into any interior
Optimum performance considering dimensions
Flexible to all music types and programs
21 cm / 8″ Passive driver with tunable low frequency (1 weight supplied)
TECHNICAL DETAILS
TYPE: 2 way – 3 drivers
RECOMMENDED AMPLIFIER (WITHOUT CLIPPING)*: 40 – 150 Watts
PEAK POWER: 300 Watts
IMPEDANCE (AVERAGE/MINI): 8 / 4 Ohms
EFFICIENCY (2.83V/1M): 88 dB
FREQUENCY RESPONSE (+/- 3 dB): 50 Hz – 28 kHz
ULTRA LOW FREQUENCY DRIVER: 1 x 210 mm / 8″ Atohm UFR210
BASS / MIDRANGE DRIVER: 1 x 150 mm / 6″ Atohm LD150
TWEETER: 1 x 20 mm / 0,75“ Atohm SD20
DIMENSIONS (width x depth x height in mm) (approx. inches): 250 x 250 x 870 / 9.84″ x 9.84″ x 34.25″
WEIGHT Kg (approx. lbs.): 14 kg / 30.8 lbs
* Power without clipping: the use of an amplifier beyond its limits provokes clipping of the sign
