Description
Pure Theatre CR50 Ceiling Recessed Projector Lift is our most popular model and is designed to conceal projectors in your ceiling space.
HIDE YOUR PROJECTOR
The CR50 projector lift is our most popular retractable projector ceiling mount used to hide your projector into the ceiling when it’s not being used.
The CR50 Ceiling Lift fits all of the most popular 4K projectors allowing you to be future proof for years to come.
The motorised feature of the projector lift allows it to retract at the touch of a button.
Key Features of our Projector Lifts
Concealed Solution
A unique lightweight aluminium construction encases the projector whilst retaining a smooth exterior profile. This enables home owners to have a fully recessed ceiling lift mechanism that is only seen when it’s meant to be.
Easy Installation
As with our screens, lifts are designed with installation in mind, and can easily be fitted to standard ceilings creating the most compact in-ceiling projector lifts available. Our unique mounting system means you don’t even have to paint the ceiling after fitting
Built In Control System
Designed and programmed in-house, our control system provides the most advanced features of any screen in the world.
Quiet and Precise
Our 24v DC linear actuator drive motors provide the fastest, most reliable, and precise operation. Linked to our own advanced current sensing control system ensures that the ceiling lift closes seamlessly every time with near silent operation of only 35dB.
Side View Dimensions
The side view shows the CR50 will fit in standard 8″ joists, with a distance of 595mm between joists. It is normal to trim a section from one joist to fit the ceiling lift.
Rear View Dimensions
The side view shows the CR50 will fit in standard 8″ joists, with a distance of 595mm between joists. It is normal to trim a section from one joist to fit the lift.
AVAILABLE IN YOUR CHOICE OF COLOUR
Pure Theatre Projector Lift’s can be Powder Coated in-house to allow for a custom finish in your choice of colour. For an additional charge, our expert engineers can help to conceal your Projector Lift just that bit further to allow for an effortless blend into any chosen living space.
Specification
| SKU | CR50-LFT |
|---|---|
| Manufacturer | Pure Theatre |
| Colour | White |
| Lift Dimensions (W x D x H) | 70cm x 67cm x 21cm |
| Max. Projector (W x D x H) | 54cm x 52cm x 19cm (extendable to 22cm) |
| Travel | 16cm |
| Maximum Weight (kg) | 35 kg |
| Raise / Lower time | 5 seconds |
| Noise: | 35 decibels |
| Power Supply | 100-240VAC 50/60Hz |
| Power Usage | max: 375W / Stationary: |
| Warranty | 5 years return to base |
| Width | 80 |
| Depth | 63 |
| Height | 30 |
| Weight (Kg) | 19 Kg |
Special order item.
